ADPRO iFT - Device Connectors; Physical Port Overview

iFT Gateway Hardware Installation Manual ADPRO
14 33104_01
5 Connectors
TheimagebelowindicatestheconnectorsontheXOdevice:
1 Micro SD:memorycardslot. 5 Ethernet:networkconnector(RJ45)
2 USB1:forXOI/OInterfaceUSBmoduleor
3G/4Gwingle.
6 HDMI:donotuse.
3 USB2:forXOI/OInterfaceUSBmoduleor
3G/4Gwingle.
7 DC 5V:3.5mmjackforpowersupply(5VDC,
2A).
4 AV/OUT:audiolineout 8 StatusLED
Caution!
Theaudioout(AV/OUT)andpowerin(DC 5V)connectorslooksimilar.Takecaretousethecorrect
connectors.
