J9
J10
J11
J12
Player 2 Buttons
1. (Red) +12V
2. (Blue) OUT
3. (Black) GND
4. (White) IN1
5. No Use
6. No Use
Player 3 Buttons
1. (Red) +12V
2. (Blue) OUT
3. (Black) GND
4. (White) IN1
5. No Use
6. No Use
Player 4 Buttons
1. (Red) +12V
2. (Blue) OUT
3. (Black) GND
4. (White) IN1
5. No Use
6. No Use
5V/12V Input DC
J13
J14
J15
J16
USB To Computer
Coin Door Player-1
1. (White) +12V
2. (Black) GND
3. (Red) IN1
4. (Yellow) IN2
5. (Blue) GND
6. (Brown) OUT1
7. (Orange) OUT2
8. (Green) +12V
Coin Door Player-2
1. (White) +12V
2. (Black) GND
3. (Red) IN1
4. (Yellow) IN2
5. (Blue) GND
6. (Brown) OUT1
7. (Orange) OUT2
8. (Green) +12V
Coin Door Player-3
1. (White) +12V
2. (Black) GND
3. (Red) IN1
4. (Yellow) IN2
5. (Blue) GND
6. (Brown) OUT1
7. (Orange) OUT2
8. (Green) +12V
J17
Coin Door Player-4
1. (White) +12V
2. (Black) GND
3. (Red) IN1
4. (Yellow) IN2
5. (Blue) GND
6. (Brown) OUT1
7. (Orange) OUT2
8. (Green) +12V
