ADTECH9 Ser
ies CNC
P
rogram
ming Ma
nual
G01 Program
ming Diagram
2.1.4.
Arc interpolatio
n (G02, G03)
Function:
Used to mov
e the tool in arc t
rack
Format:
On X
—
Y
plane
G17 { G02 /
G03 } X__
Y__ { ( I__ J__ ) /
R__ } F__ ;
On X
--
Z plane
G18 { G02 /
G03 } X__ Z__ { (
I__ K
__ ) / R__ } F__ ;
On
Y
--
Z plane
G19 { G02 /
G03 }
Y__ Z__
{ ( J__ K
__ ) / R__ } F
__ ;
24
26
