ADTRAN NetVanta 1230 Series User Manual

61700594G1-34B Copyright © 2009 ADTRAN, Inc. 27
APPENDIX A. CONNECTOR PIN DEFINITIONS
The following tables provide the pin assignments for the base unit.
Base Unit Pinouts
Table A-1. 10/100Base-T Ethernet Port Pinouts
Pin Name Description
1 TX1 Transmit Positive
2 TX2 Transmit Negative
3 RX1 Receive Positive
4, 5 — Unused
6 RX2 Receive Negative
7, 8 — Unused
Table A-2. SFP Slot Pinouts
Pin Name Pin Name
1RX_LOS11RGND
2RGND12RX_DAT-
3RGND13RX_DAT+
4MOD_DEF(0)14 RGND
5 MOD_DEF(1) 15 VddR
6MOD_DEF(2)16 VddT
7 TX_DISABLE 17 TGND
8TGND18TX_DAT+
9TGND19TX_DAT-
10 TX_FAULT 20 TGND
