Page #28 background image
Appendix A. Connector Pin Definitions NetVanta 1230 Series Hardware Installation Guide
28 Copyright © 2009 ADTRAN, Inc. 61700594G1-34B
Table A-3. 1000Base-T Gigabit Ethernet Port Pinouts
Pin Name Description
1 TRD0+ Transmit/Receive Positive
2 TRD0- Transmit/Receive Negative
3 TRD1+ Transmit/Receive Positive
4 TRD2+ Transmit/Receive Positive
5 TRD2- Transmit/Receive Negative
6 TRD1- Transmit/Receive Negative
7 TRD3+ Transmit/Receive Positive
8 TRD3- Transmit/Receive Negative
