NetVanta 3100 Series Hardware Installation Guide Physical Descriptions
61700600L2-34C Copyright © 2015 ADTRAN, Inc. 17
If the factory default switch is pressed and held for 5 seconds after boot, the switch ports on the
NetVanta 3120 will default to 10.10.10.1 and all access policies will be removed from those interfaces.
If the factory default switch is pressed for 30 seconds, a default configuration will overwrite your
existing configuration and reboot the unit.
4 Switch Port Interfaces
Ports 1 through 4 are RJ-45 connectors used to access the 10/100Base-T Ethernet switch.
Power Connection
The rear panel has a 12V input for the DC power supply included in the shipment. Refer to Wall
Mounting a Single NetVanta 3140 (P/N 1700341F1) on page 28 for connection details.
NetVanta 3130
The NetVanta 3130 is a fixed-port ADSL2+ IP access router with an integral four-port Ethernet switch. It
provides a single ADSL network interface and four auto-sensing 10/100Base-T Ethernet LAN interfaces.
This product is ideal for carrier-bundled service offerings and enterprise-level Internet access for secure,
high-speed corporate connectivity. In addition to supporting ADSL (Annex A), and ADSL2, the
NetVanta 3130 supports today’s most advanced ADSL technology, ADSL2+, for greater reach and higher
bandwidth, up to 25 Mbps. Some models include an integrated analog modem for dial backup and
management. IPsec VPN support is included without further software upgrade. The unit is powered by a 12
VDC power supply (AC to DC power adapter included).
NetVanta 3130 Features and Specifications
The NetVanta 3130 offers the following features:
• Fixed-port ADSL router with integral 4-port Ethernet switch
• IP access router for ADSL, ADSL2, ADSL2+ networks with line rates up to 25 Mbps
• Supports ATM, PPP over ATM, and PPPoE over ATM
• Integrated analog modem for dial backup or remote management (1700610L2 only)
• ADTRAN Operating System (AOS) command line interface (CLI)
• User-friendly, web-based graphical user interface (GUI)
• Standards-based eBGP/iBGP, OSPF, RIP, static routing and bridging protocols
• Integral stateful inspection firewall protects against denial of service (DoS) attacks
• Includes IPsec VPN supporting DES/3DES/AES encryption
• Compatible with IPsec VPN-equipped devices
• Quality of service (QoS) with low latency queuing (LLQ), weighted fair queuing (WFQ), class-based
weighted fair queuing (CBWFQ), and DiffServ marking
• Built-in alert and logging mechanisms
• Network address translation (NAT/NAPT), 1:1 NAT port translation, and NAT Traversal version 2
• NAT-compliant SIP ALG
• DHCP client, server, and relay
• XAUTH including RADIUS and RSA SecurID
The default switch must be pressed WHILE the STAT light is flashing green. Do not
press the default switch BEFORE the STAT light is flashing green, as this will cause
boot to be missed.
