NetVanta 4300/4400 Series Physical Descriptions
61200890E2-34T Copyright © 2019 ADTRAN, Inc. 17
• Mountable in a 19-inch rack
• Power Supply: Worldwide auto-ranging AC (120 to 240 VAC)
• Operating Temperature: 0°C to 50°C
• RoHS compliant (Telecommunications exemption)
Network Interface Modules and Dial Backup Interface Modules Supported
The main base unit supports a variety of interchangeable NIMs and DIMs. The NIMs available in this
series provide a variety of WAN connectivity options, including the following:
•56K/64K (DDS)
• T1/FT1
• T1/FT1 + DSX-1
•Dual T1
• E1/FE1
• E1/FE1 + G.703 Drop
• Serial (V.35/X.21/EIA 530)
• ADSL, Annex A and Annex B
• SHDSL, Annex A and Annex B
•USB WWAN
• Octal T1/E1 Wide Module (no external CSU/DSU needed)
If needed, an analog modem DIM, ISDN BRI U, or ISDN BRI S/T DIM can plug onto the NIM, providing
dial backup capability. Refer to
Installing Dial Backup and Network Interface Modules on page 49 for
more details.
Refer to Using a USB Cellular Modem with the NetVanta USB WWAN NIM on page 51 for details on
installing and removing a USB cellular modem from the USB WWAN NIM.
SFP Module Slots
The NetVanta 4430 has two small form-factor pluggable (SFP) slots that accept a number of industry
standard SFP modules. The SFP modules provide Gigabit Ethernet fiber connectivity for high-speed
uplinks. For a list of supported SFP modules, visit the ADTRAN website at http://www.adtran.com.
NetVanta 4430 Shipping Contents
Each NetVanta 4430 unit is shipped in its own cardboard shipping carton. Open each carton carefully, and
avoid deep penetration into the carton with sharp objects.
After unpacking the unit, inspect it for possible shipping damage. If the equipment has been damaged in
transit, immediately file a claim with the carrier and contact ADTRAN Customer Service (refer to the
Support page on the ADTRAN website at
http://www.adtran.com/support).
