ADTRAN NetVanta 4305 Hardware Installation Guide

Description
1 R Transmit data toward the DTE–Ring
2 T Transmit data toward the DTE–Tip
3 — Unused
4 R1 Receive data from the DTE–Ring 1
5 T1 Receive data from the DTE–Tip 1
6-8 — Unused
Description
1 R Transmit data toward the DTE–Ring
2 T Transmit data toward the DTE–Tip
3 — Unused
4 R1 Receive data from the DTE–Ring 1
5 T1 Receive data from the DTE–Tip 1
6-8 — Unused
Description
1, 2 — Unused
3 R ADSL Ring
4 T ADSL Tip
5, 6 — Unused
Description
1 T2 Loop 2–Tip
2 R2 Loop 2–Ring
3 — Unused
4 T1 Loop 1–Tip
5 R1 Loop 1–Ring
6-8 — Unused
NetVanta 4300/4400 Series
61200890E2-34T Copyright © 2019 ADTRAN, Inc. 59
Table A-8. DSX-1 Connector Pinouts
Pin Name
Table A-9. G.703 Connector Pinouts
Pin
Name
Table A-10. WAN-ADSL NIM Connector Pinouts
Pin Name
Table A-11. WAN-SHDSL Connector Pinouts
Pin Name
