Product Overview NetVanta 5305 Hardware Installation Guide
20 Copyright © 2010 ADTRAN, Inc. 61200990L1-34N
LAN Interfaces (ETH 0/1, ETH 0/2)
The NetVanta 5305 provides two RJ-48C connectors on the rear panel system controller module for
routing data traffic and for local management access. See Table A-1 on page 33 for the 10/100Base-T
Ethernet interface pinouts. The 10/100Base-T Ethernet ports provide the following:
• Auto-sensing
• Primary data port service
• Secondary DMZ port service
• Local management access
