NetVanta 5305 Hardware Installation Guide Option Modules
61200990L1-34N Copyright © 2010 ADTRAN, Inc. 25
Clock Source
•Network
Internal
Diagnostics
Network Loopbacks: Line, payload, remote
Test Pattern Generation and Detection: QRSS, 2
15
- 1, 2
20
- 1, all ones, all zeros
Compliance
EMC - see Electromagnetic Compatibility (EMC) Table on page 6.
AS/ACIF S016
ETSI TBR 12/TBR 13
ACTA/FCC Part 68
IC CS-03
UL/CUL 60950
EN 60950
IEC 60950
AS/NZS 60950
RoHS Compliant (Telecommunications exemption)
Environmental
Operating Temperature: 0°C to 50°C
Storage Temperature: -20°C to 70°C
Relative Humidity: Up to 95 percent, noncondensing
Physical
5.63-inch W x 8.63-inch D
T1/E1 Mode Switch
The Octal T1/E1 Wide Module is shipped with the T1/E1 mode switch (located on the circuit board) set to
T1. If you require E1 functionality, use your thumbnail to slide the E1 mode switch to the
ON position (as
shown in the figure below).
A different service provider can be used on each interface. Each interface has an
independent clock.
No external CSU/DSU is needed with the T1/FT1 interface.
