Advanced Electronics Mx-4400 - Installation; Panel Identification and Enclosures

www.advancedco.com
11
2 Installation
2.1 Identification of Parts
The following diagrams show the major parts of the panels.
2.1.1 Mx-4100
2.1.2 Mx-4200 & Mx-4400
Earth Lead to
Cover
Chassis
Assembly
AC Mains
Input
Battery
Leads
Rear
Enclosure
Chassis
Assembly
Rear
Enclosure
AC Mains
Input
Battery
Leads
