5.10 Appendix 10 – Mx Series Product Capabilities / Max Limits
This section gives details on the maximum capabilities for each of the products in the range. Some of the items
can only be utilised via the PC CONFIG tool and these are annotated accordingly.
Item
4100
4200
4400
4010 /
4020
Mxp-
010
Mxp-
020
Comments
Max № of Loops
1
2
4
0
0
0
Max № of Resident Zones
100
200
200
100
100
100
Highest Resident Zone №
250
1000
1000
1000
1000
1000
Max № of System Zones
250
1000
1000
1000
1000
1000
Max № of Points
300
1000
1000
2
9
65
№ of On-board Points
31
43
56
2
9
9
№ of On-board Sounders
2
2
4
0
0
0
№ of On-board Relays
(including O/C Outputs)
4
10
10
0
0
0
№ of Switch Inputs
8
8
8
1
8
21
8
21
(56)
22
See footnotes
Max № of Time Clocks
3
10
10
--
3
3
Max № of Ringing Styles
10
20
20
10
10
10
Max № of Output Groups
200
200
200
200
200
200
Max № of Output Group
Lines
250
1150
1150
250
250
250
Requires PC CONFIG to
define more than one line per
Output Group
Max № of Passwords
12
12
12
12
12
12
Max № of Sectors Available
50
50
50
50
50
50
PC CONFIG Only
Max № of Input Events
100
250
250
100
100
250
PC CONFIG Only
Max № of Logic Blocks
50
100
100
50
50
50
PC CONFIG Only
Max № of Logic Terms
23
100
500
500
100
100
100
PC CONFIG Only
Max First Loop №
20
19
17
--
--
--
PC CONFIG Only
21
Only available if a display card is fitted.
22
Requires PC CONFIG to define the 50-Way I/O card for additional inputs.
23
Max № of logic terms available to the user depends upon the number of logic blocks defined. Each logic block requires a terminator term.
This terminator uses up one of the available logic terms. Therefore, the number of logic terms available for use will be the Max № of Logic
terms – the № of Logic blocks used – for example, using 20 logic blocks in an Mx-4400 will give 500-20=480 Logic Terms available to use.
