Advanced Instruments Anoxomat Mark II CTS User Manual

2
Anoxomat Mark II CTS User’s guide
Table of contents
Safe use 4
Symbol conventions 4
General cautions 5
FCC requirements 5
Foreword: Intended use 6
Chapter 1
Installation and setup 7
1.1 Find a location for the instrument 7
1.2 Obtain additional items 7
1.3 Unpack the instrument 7
1.4 Install the primary (standard) gas supply 8
1.5 Install the recipe printer (optional) 9
1.6 Connecting to a computer or network (optional) 9
1.7 Power up the instrument 9
1.8 How to input data 10
1.9 Setting up the instrument 10
1.10 Standard gas mixture 12
1.11 Registration setup (optional) 13
1.12 Activating the printer (optional) 15
1.13 Activating the data interface (optional) 15
Fig. 1.1 Anoxomat Mark II CTS and accessories 8
Fig. 1.2 Tube and gas connections 9
Fig. 1.3 Power entry and on/o switch 9
Fig. 1.4 Red touch screen protection label 9
Fig. 1.5 Main screen 10
Fig. 1.6 Setup code 10
Fig. 1.7 Main setup 10
Fig. 1.8 Gas connection setup 10
Fig. 1.9 Edit gas mixture 11
Fig. 1.10 Setup language 11
Fig. 1.11 Set date/time 11
Fig. 1.12 Unlock registration code 13
Fig. 1.13 Registration 13
Fig. 1.14 Jar setup 13
Fig. 1.15 Add user 14
Fig. 1.16 Registered user 14
Fig. 1.17 Connect printer 15
Fig. 1.18 Choose printer 15
Fig. 1.19 Enter fixed ip address 15
Fig. 1.20 Set IP address of network card 16
Table 1.1 Anoxomat Mark II CTS packing list 7
Table 1.2 Gas supply mixtures and jar composition results 12
Chapter 2
Instrument operation 17
2.1 Function of major components 17
2.2 Operating procedure 17
2.3 Process report 18
2.4 End of recipe 19
2.5 Quality Assurance program 19
2.6 Changing the Quality Assurance level for one run 20
2.7 Changing the default Quality Assurance
level for a recipe 20
Fig. 2.1 Connect jars 18
Fig. 2.2 Process report 18
Fig. 2.3 Active recipe 18
Fig. 2.4 Set quality assurance level 20
Fig. 2.5 Program recipes 20
Fig. 2.6 Edit recipe 20
Chapter 3
Optional functions 21
3.1 Barcode scanner 21
3.2 Registration Input screen 21
3.3 Pre-programmed recipes 22
3.4 Additional jar connections 22
