Advanced 3320 User Manual

The Advanced
®
Osmometer Model 3320 Service Manual
17
Overview
A. Power Entry Module
B. Secondary Cooling Fan
C. RS-232 Port
D. Printer Port
E. Barcode Port
F. Cooling Fan
G. Sample Probe Bin Number
H. Sample Probe
I. Block Probe
A
B
D
C
H
F
M
E
P
K
Q
O
L
J. Block Probe Bin Number
K. Solenoid
L. Solenoid Retainer
M. Sample Handling Assembly
N. Actuator Switch Cable
O. Central Processor Board
P. Application Board
Q. Power Supply
J
G
I
N

Advanced 3320 Specifications

General

Brand	Advanced
Model	3320
Category	Measuring Instruments
Language	English
