Advanced Ex-3001 User Manual

10
RELEASE ACTIVATED
00:00:05 Elapsed
When the countdown timer has elapsed, the actuating output is
activated to start the release of the extinguishant.
The display now shows the time elapsed since the release of
extinguishant commenced.
In addition, the Release Imminent LED turns ON steady.
GAS RESET INHIBITED
RELEASE ACTIVATED
10 Seconds Elapsed
When the discharge is complete (either time elapsed or flow
detected) the display indicates the discharge is complete.
It is now possible to silence the flooding zone sounders.
DISCHARGE COMPLETE
(No Flow Detected)
GAS RESET INHIBITED
RELEASE ACTIVATED
10 Seconds Elapsed
If confirmed by the detection of the flow of the extinguishant, the
display shows RELEASE CONFIRMED (Released Condition) and
the RELEASED LED turns ON steady.
If previously silenced, the internal buzzer will re-sound. Press the
MUTE button to silence the buzzer.
RELEASE CONFIRMED
DISCHARGE COMPLETE
GAS RESET INHIBITED
RELEASE ACTIVATED
20 Seconds Elapsed
When the extinguishant has been fully released (and if
programmed), the panel will either automatically, or will prompt for
manual confirmation, activate the output to control the extract fan.
This is indicated on the display as EXTRACT RUNNING or
PRESS ✔ to EXTRACT).
When the discharge is complete, the display prompts that the
panel can be reset.
DISCHARGE COMPLETE
EXTRACT RUNNING
RESET ALLOWED
To reset the panel, press the RESET button. A Reset Control menu may appear – use the  buttons to
highlight the appropriate option, then press the ✔ button to select.
Section 4.12.2
Reset of the Activated Condition / Release Signal.
NOTE: In accordance with EN 12094-1, the ECD shall not permit a reset until
either the RELEASED condition has been established (flow detected) or until
after a programmable time following activation of the mechanism to release the
extinguishant.
NOTE: Depending on programming, the EXTRACT condition may persist after the panel is reset for up to 120
minutes. This will be indicated on the normal status display (Extract Running).
Section 4.11
Released Condition.
NOTE: In accordance with EN 12094-1, the activated / release condition may be
established without the detection of a fire alarm or manual release. If the panel
detects the release of extinguishant, it will immediately indicate the released
condition.
