In the above examples:
[1] The control panel recognised and recorded an open-circuit fault condition on the wiring of Detection Zone 3.
[2] User 4 disabled the operation of, and fault reporting from, Detection Zone 3.
[3] The control panel recognised and recorded a fire alarm condition on Detection Zone 3.
2.4.1.4.2 Alarm Counter
Alarm Counter.
The Panel records the number of times that the fire alarm condition has
occurred at the panel.
On selection, the display shows the alarm count.
In the example the panel has entered the fire alarm condition 4
times since it was installed.
Press the ESC button to return to the previous menu.
The panel increments the count by one each time it changes from the normal condition to indicate a fire alarm
condition. Whilst in the fire alarm condition, and until it is reset, further fire alarm events do not increment the
counter.
2.4.1.5 Software Versions
[Software Versions]
PANEL : 99.00
RSI-1 : 99.00
RSI-2 : 99.00
RSI-3 : 99.00
RSI-4 : 99.00
On selection, the display shows a list containing the panel and any
configured remote status indicators along with the version of
software installed in each device.
Press the buttons to scroll through the list of entries.
Press the ESC button to return to the previous menu.
2.4.1.6 Panel Levels
[Panel Levels]
SYSTEM VOLTS 27.08V
BATTERY (V) 27.42V
CHARGER (V) 27.55V
Temperature 21deg
On selection, the display shows a list containing key information
about power supply related levels.
Press the buttons to highlight the list of entries.
Press the ESC button to return to the previous menu.
System Volts relates to the supply voltage present on the main card all other values are measured at the power
supply module. Where the communication link to the power supply module is broken the values are replaced by
a ‘-‘ character.
2.4.2 Test
[Test Menu]
ZONES .
DISPLAY
BUZZER
MANUAL TRIGGERS
Press the buttons to scroll through the list and press the ✔
button to select the required test option.
