ADAM-2000 Series User Manual 58
B.2.4 ADAM-2031Z
Wireless Sensor Network Temperature and Humidity Sensors Node
Table B.5: ADAM-2031Z Function Table
Address 4X Description Attribute Value
00001 Temperature Input Read 0x0000 ~ 0xFFFF*
00002 Humidity Input Read 0x0000 ~ 0xFFFF**
20001 Module Status Read Bit0: 0; Initial Mode
Bit0: 1; Normal Mode
Bit1: 0; No External Power Input
Bit1: 1; External Power Input
20002 LQI Read 0x0000~0x00FF; 0x0000: No Signal,
0x00FF: Excellent
20003 Battery Level Read 0x0000; Low
0x4000; Poor
0x8000; Normal
0xC000; Good
0xFFFF; Excellent
20004 Device Inactive Period Read 0~51840; 0~51840 counts (5 seconds
per count), 0xFFFF: Over 3 days
Note!
* The temperature T is calculated by inserting temperature signal output
S
T
into the following formula (result is in
o
C).
Note!
** The humidity RH is calculated by inserting humidity signal output
S
RH
into the following formula (result is in %RH)
T 46.85– 175.72x
S
T
2
16
-------
+=
RH 6125x
S
RH
2
16
---------
+=
