93 Appendix B
B.8 External Keyboard Connector (CN12)
Table B.7: Keyboard and mouse connector (CN11)
Pin Signal
1 KB DATA
2N/C
3GND
4 KB VCC
5 KB CLK
6 N/C
Table B.8: External keyboard connector (CN12)
Pin Signal
1CLK
2DATA
3NC
4GND
5 VCC
