Advantech AIMB-742 User Manual

105 Appendix B
B.30 PCI Bus Map
Table B.30: PCI bus map (for VE, E2 version)
Function Signals: Device ID INT# pin GNT REQ
Onboard LAN1 -- INT E -- --
Onboard LAN2 AD26 INT H GNT F REQ F
Bridge AD22 GNT E REQ E
PCI slot 1 AD31 INT B, C, D, A GNT A REQ A
PCI slot 2 AD30 INT C, D, A, B GNT B REQ B
PCI slot 3 AD29 INT D, A, B, C GNT 1 REQ 1
PCI slot 4 AD28 INT A, B, C, D GNT 2 REQ 2
PCI slot 5 AD27 INT B, C, D, A GNT 3 REQ 3
Table B.31: PCI bus map (for VG, G2 version)
Function Signals: Device ID INT# pin GNT REQ
Onboard LAN2 AD26 INT H GNT F REQ F
Bridge AD22 GNT E REQ E
PCI slot 1 AD31 INT B, C, D, A GNT A REQ A
PCI slot 2 AD30 INT C, D, A, B GNT B REQ B
PCI slot 3 AD29 INT D, A, B, C GNT 1 REQ 1
PCI slot 4 AD28 INT A, B, C, D GNT 2 REQ 2
PCI slot 5 AD27 INT B, C, D, A GNT 3 REQ 3
