AIMB-742 User’s Manual
26
2.16 Line Out, Mic
IN connector (CN55)
The Line Out is to output th
e audio signal to external audio device, like
speakers or headphon
es. The Mic IN
is to input the audio signal via
microphones.
2.17 Audio input from
CD-ROM (CD IN; CN56)
The CD IN
is a connector for CD
-ROM to i
nput the audi
o signal.
2.18 Aux Line-In connector (AUX IN; CN57)
The connector is for audio de
vice with Line-in connector.
