95
Appendix B
B.11 External Speaker Connector (CN17)
The motherboard has its own buzzer. You
can als
o connect it to the
exter-
nal speaker on your computer chassis.
B.12 Reset C
onnector (CN18)
Table B.11: External Speaker Connecto
r (CN17)
Pin
Function
1
Buzzer
2N
C
3
Buzzer
4
Speaker out
Table B.12: Reset connector (CN18)
Pin
Signal
1
RESET
2G
N
D
1
110
112
