2.9 External Keyboard Connector (CN12)
In addition to the PS/2 mouse/keyboard connector on the AIMB-742's
rear plate, there is also an extra onboard external keyboard connector.
This gives system integrators greater flexibility in designing their sys-
tems.
2.10 CPU Fan Connector (CN14)
If fan is used, this connector supports cooling fans of 500mA (6W) or
less.
2.11 System FAN connector (CN15 and CN37)
If fan is used, this connector supports cooling fans of 500mA (6W) or less.
CN12
CN14
