AIMB-742 User’s Manual 48
3.10 Spread Spectrum Control
Figure 3.12: Spread Spectrum Control screen
3.10.1 CPU Clock Ratio
Key in a DEC number to setup the CPU Clodk Ratio. (Min=8; Max=50).
This item only shows up under some special situations.
3.10.2 Spread Spectrum
To enable/disable the spread spectrum. The Choice : "Disabled", "-
0.40%", "- 0.50%", "- 0.60%" and "- 1.00%".
3.11 Password Setting
To change the password:
1. Choose the “Set Password” option from the “Initial Setup Screen”
menu and press <Enter>.
The screen will display the following message:
Press <Enter>.
2. If the CMOS is good or if this option has been used to change the
default password, the user is asked for the password stored in the CMOS.
The screen will display the following message:
Please Enter Your Password
