xi
*
Specifications are subject to change without notice.
AIMB-763VG specications summary
BIOS features 4 Mb Flash ROM, Award BIOS, PnP, WfM2.0, DMI2.0, SM
BIOS 2.3
Industry standard PCI 2.2, USB 2.0
Manageability WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, Chassis
Intrusion
Internal connectors 2 x USB 2.0 connectors for 4 additional USB 2.0 ports
1 x CPU fan connector
1 x Chassis fan connector
1 x Power fan connector
1 x 24-pin ATX power connector
1 x 4-pin ATX 12 V power connector
1 x CD in connector
1 x Front panel high-denition audio connector
1 x S/PDIF out connector
1 x TPM connector (Option)
1 x COM port (COM2)
1 x 3-pin Power LED connector (PLED)
Power Requirement ATX power supply (with 20-pin and 4-pin 12 V plugs)
Form Factor ATX form factor:12 in x 9.6 in (304.8 mm x 243.84 mm)
Support CD contents Device drivers
