AIMB-763 1-11
The CPU ts in only one correct orientation. DO NOT force the CPU into the
socket to prevent bending the connectors on the socket and damaging the
CPU!
6. Close the load plate (A), then push
the load lever (B) until it snaps into
the retention tab.
A
B
The motherboard supports Intel
®
Pentium
®
D or Intel
®
Pentium
®
4 LGA775
processors with the Intel
®
Enhanced Memory 64 Technology (EM64T),
Enhanced Intel SpeedStep
®
Technology (EIST), and Hyper-Threading
Technology. Refer to the Appendix for more information on these CPU
features.
