3 DS-780 User Manual
Chapter 1 General Introduction
1.3 Hardware Specifications
 CPU: Intel® Core™ Skylake-U series i7-6650U /i7-6600U/ i5-6360U /i5-6300U/
i3-6100U/Celeron-3955U
 System Chipset: SoC solution, built-in Intel® Core™ Skylake-U processor
 BIOS: AMI uEFI 64 Mbit Flash BIOS
 System Memory: 2 x DDR4 SO-DIMM sockets, support DDR4 2133 MHz up to
32 GB (Max. 16GB per each SO-DIMM socket)
 Processor Graphics: Intel® IRIS Graphics 540 (i7-6650U / i5-6360U), Intel®
HD Graphics 520 (i7-6600U/i5-6300U/i3-6100U), Intel® HD Graphics 510 (Cel-
eron-3955U)
 Storage: Supports 1 x 2.5" SATA HDD/SSD
 Watchdog Timer: Supported by Advantech SUSIAccess API
 I/O Interface:
– COM: 1 x RS-232
– USB: 4 x USB 3.0
– Audio: 1 x SPDIF / Line-Out / Mic-in
 Ethernet Chipset: 1 x Intel i219, 1 x Realtek 8111G
 Speed: 10/100/1000 Mbps
 Interface: 2 x RJ-45 jacks with LED
 Standard: IEEE 802.3 (10 / 1000 Base-T, 100 Base-TX) or IEEE 802.3u (Auto-
Negotiation)
 Expansion
– Mini PCIe: 1 socket internal (Full size), support mSATA interface
– M.2(2230/1630 E Key).
