2.1 DS-780 Front and Rear Views
Figure 2.1 Front view
Figure 2.2 Rear view
2.5” Storage Bracket LAN2 USB3.0 x 2
SPDIF/
Line out/
Mic in
PWR Button
Status LED
WIFI/HDD
19V DC-in
HDMI x 3
USB3.0 x 2 LAN1
COM
