13 DS-780 User Manual
Chapter 2 Hardware Installation
2.4 Hardware Installation
2.4.1 Memory Installation
[Top side]
1. Loosening the 4 fixing screws on the side of top cover.
2. Remove the top cover.
3. Insert the memory module into memory socket
4. Assemble back the heatsink cover with the 4 screws
Figure 2.11 Memory module installation-Top side
MEMORY
