DS-780 User Manual 32
 PCH-IO Configuration
PCH-IO Parameters
– PCI Express Configuration
PCI Express Configuration settings
– USB Configuration
USB configuration settings
a.USB Precondition
b.XHCI Disable Compliance Mode
c.USB port Disable override
– HD Audio
Control detection of the HD-Audio device.
Disable=HDA will be unconditionally disabled
Enable=HDA will be unconditionally enabled
Auto= HDA will be enabled if present, disable otherwise.
– LAN1 Control
Enable or disable onboard NIC
– LAN2 Control
Enable or disable onboard NIC
– PCIe Wake
Enable/disable PCIE to wake the system from S5.
– Wake on WLAN Enable from DeepSx
Enable/Disable PCI Express wireless LAN to wake the system from DeepSx.
– State after G3
Specify what state to go to when power is re-applied after a power failure (S3
state)
