EKI-1528/1526 User Manual 4
1.3.5 General
LED Indicators:
– System: Power, System Status
– LAN: Speed, Link/Active
– Serial: Tx, Rx
Alert Tool: Built-in buzzer and RTC (real time clock)
Reboot Trigger: Built-in WDT (watchdog timer)
1.3.6 Power Requirements
Power Input: 100 to 240 VAC, 47 to 63 Hz
Power Consumption:
– EKI-1528: 8W
– EKI-1526: 10W
1.3.7 Environment
Operating Temperature: 0 to 60
o
C (32 to 140
o
F)
Storage Temperature: -20 to 85
o
C (-4 to 185
o
F)
Operating Humidity: 5 to 95% RH
1.3.8 Regulatory Approvals
EMC: CE Class A, FCC Part 15 Subpart B Class A
1.4 Package Checklist
One 8 or 16-port serial device server
EKI-1500 IEDG driver utility and documentation CD
One 30cm RJ45 to DB9 cable for serial connection
Rack mount kits, including 2 L-shape metal plates and 12 screws
One RS-232 loopback DB9 tester
Optional Accessories
OPT1I: 1m RJ45 to DB9 (male) cable
OPT1J: 30cm RJ45 to DB9 (male) cable
1702002600: Power Cable US Plug 1.8m
1702002605: Power Cable EU Plug 1.8m
1702031801: Power Cable UK Plug 1.8m
1702031836: Power Cable China/Australia Plug 1.8m
Note! If anything is missing or damaged, contact your distributor or sales rep-
resentative immediately.
