5.5 Description of the Right Panel
The right panel is displayed on figure 8.
F
igure 8: Right panel
The right panel contains:
• LAN1/WAN – RJ45 slot for LAN/WAN connection – see chapter 5.6.6,
• LAN2 – RJ45 slot for LAN connection – see chapter 5.6.6,
• PWR – DC power receptacle plug – see chapter 5.6.2.
11
04-09-19
