ICR
-1601
5.6.5 MicroSD Card Reader
Mak
e sure that the router is powered off prior to inserting or replacing the microSD card.
A
microSD memory card can be inserted into the router and used for the log storage. Slot
for one microSD memory card is located on the left panel of the router protected by a metal
cover. It is necessary to unscrew two screws and remove the metal cover first. Insert the
microSD card by pushing it into the slot, see figure below. Push the inserted card again to
eject it from the slot. Insert the metal cover back and screw it again.
Supported are SDXC memory cards of class 10 with size up to 32 GB.
F
igure 14: Installation of microSD memory card
17
04-09-19
