ICR
-1601
5.6.4 SIM Card Reader
Mak
e sure that the router is powered off prior to inserting or replacing the SIM card.
The
two slots for SIM cards are located on the left panel of the router protected by a metal
cover. It is necessary to unscrew two screws and remove the metal cover first. Insert the SIM
card by pushing it into the slot, see figure below. Push the inserted SIM card again to eject it
from the slot. Insert the metal cover back and screw it again.
In order for the router to function, it is necessary to insert an activated SIM card with
an unblocked PIN code. The SIM cards may have different adjusted APNs (Access Point
Names).
F
igure 13: Installation of SIM cards
Supported type of SIM cards: Micro SIM (3FF), dimensions 15.0 x 12.0 x 0.76 mm.
16
04-09-19
