ICR
-1601
5.6.2 Power Supply
There is a DC5V/2A power adapter in the package for you to easily connect DC power to
this gateway. Picture of this power adapter is on figure 11. If you power the gateway with other
DC Power Source, please make sure the DC Power voltage is in range from 5V to 18V DC.
The maximum power consumption of the router is 7 W.
Figure 11: Power adapter
The
delivered power adapter is not determined for operating at wide temperature range
environment. For operation at full temperature range purchase other industrial power
supply with required parameters.
U
nit has to be supplied by a power supply specified as a Limited Power Source (LPS) ac-
cording to clause 2.5 of IEC/UL 60950-1 or CEC/NEC Class 2 source of supply as defined
in the Canadian Electrical Code, CSA C22.1 and National Electrical Code, ANSI/NFPA 70. If
the power supply/cable provided with device is not used, always use the cables with minimum
wire size (nominal cross section) 0.5 square mm for power supply.
14
04-09-19
