Advantech ICR-1601 - Cellular Module Parameters

ICR
-1601
7.5 Technical Parameters of Cellular Module
Cellular
module
L
TE parameters
L
TE FDD Cat.4
Bit rate: 150 Mbps (DL) / 50 Mbps (UL)
Supported frequencies: B20 (800 MHz), B8 (900 MHz), B3
(1800 MHz), B1 (2100 MHz), B7 (2600 MHz)
Transmit power: 23±2.7 dBm
W
CDMA parameters
Bit
rate: 42.0 Mbps (DL) / 5.76 Mbps (UL)
Supported frequencies: B8 (900 MHz), B1 (2100 MHz)
Transmit power: 24+1/-3 dBm
GPRS/EDGE
parameters
GPRS
bit rate: 85.6 kbps (DL) / 85.6 kbps (UL)
EDGE bit rate: 236.8 kbps (DL) / 236.8 kbps (UL)
GPRS multislot class 10, EDGE multislot class 12
Supported frequencies: 900 MHz, 1800 MHz
GSM900 transmit power: 33±2 dBm
GSM1800 transmit power: 30±2 dBm
T
able 9: Technical parameters of cellular module
Antenna Requirements
• VSWR – <2:1 (Antenna input impedance response as function of frequency. This shows
the antenna resonances and its bandwidth).
• SMA – 50 Ω
• For good diversity performance, the primary and secondary antennas should have dif-
ferent polarizations.
27
