PCI/ PCI Express-Communication User Manual 4
 Data Signals:
 Dimensions
Table 1.1: Data Signals
Communication Interfaces
Bus Interface Model Name Ports Current
Loop
RS-232 RS-422 RS-485
Universal Low-Profile PCI PCI-1602UP 2 - - V ** V
PCI-1604UP 2 - V * - -
Universal PCI PCI-1601A/B 2 - - V V
PCI-1602 2 - - V V
PCI-1603 2 V V * - -
PCI-1610A/B/C 4 - V * - -
PCI-1612A/B/C 4 - V V V
PCI-1620A/B 8 - V - -
PCIe-1622B/C 8 - - V V
PCI Express PCIe-1620A/B 8 - V - -
PCIe-1622A/B 8 - V V V
1. RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
2. RS-422: Tx+, Tx-, Rx+, Rx-, RTS+, RTS-, CTS+, CTS-
3. RS-485: Data+, Data-, GND
4. Current loop: Tx+, Tx-, Rx+, Rx-
* TxD, RxD, Rx+, Rx-, RTS+, RTS-, CTS+, CTS-, GND, RI (for PCI-1603, PCI-1604UP,
PCI-1610A/ B/C_RS-232)
** TxD, RxD, Rx+, Rx-, RTS+, RTS-, CTS+, CTS-, GND (for PCI-1602UP_RS-422)
Size Model
170 x 110 mm PCIe-1620A/B, PCIe-1622A/B
185 x 100 mm PCI-1610A/B/C, PCI-1612A/B/C, PCI-1620A/B, and PCI-1622B/C
123 x 92 mm PCI-1601A/B, PCI-1602, and PCI-1603
119.91x 64.41mm
(Low Profile PCI MD1)
PCI-1602UP, and PCI-1604UP
