Advantech SPC-815 - Without Button Extension for Built in SPC-815-MLAG & SPC-821- MLAG Multi Touch Industrial Monitor

SPC-800(M) User Manual 6
1.3.2 Without Button extension for built in SPC-815-MLAG & SPC-
821-MLAG Multi Touch Industrial Monitor
Advantech Part Number SPC-815-MLAG SPC-821-MLAG
General
Weight
6.8g(W/O ARM Mount)
7.2g(W ARM Mount)
7.6Kg(W Vesa Mount)
9.6g(W/O ARM Mount)
10Kg(W ARM Mount)
10.4Kg(W Vesa Mount)
System
Dimension
(W x D x H mm)
402.19mm x 333.19mm x 67mm
(W/O ARM Mount)
402.19mm x 333.19mm x
160mm (W ARM Mount)
402.2mm x 333.2mm x 86.6mm
(W Vesa Mount)
546.69mm x 420.34mm x 67mm
(W/O ARM Mount)
546.69mm x 420.34mm x 160mm
(W ARM Mount)
546.69mm x420.34mm x 86.6mm
(W Vesa Mount)
Monitor Board
Dimension
(W x D x H mm)
145 x 104 x20 mm
Enclosure
Front bezel: Die cast aluminum alloy
Back housing: Die cast aluminum alloy
Mounting
ARM mounting (Pendant and Pedestal)
VESA mounting
Power Input
Voltage
24VDC +25%/- 20%
Power
Consumption
(DP+HDM+RX)
20.6W 32W
System Design Fanless
I/O
USB USB 2.0x1 (Type B) ,USB 3.0 x2,USB 2.0 x 1 (Front)
Display Port DP Port x1
HDMI Port HDMI Port x1
Optional Interface
for Long Distance
RX:RJ-45 port*1
Chip: Valens VS2010, 100M
For Long distance function, please use CAT6 Ethernet Cable
Display
Backlight Control OSD setting brightness
Display Type TFT LCD TFT LCD
Display Size 15.6" 16:9 21.5" 16:9
Max. Resolution HD 1366 X 768
FHD 1920
X1080
(option)
FHD 1920x1080
LCD Luminance
(cd/m²)
400 450 250
Backlight MTBF
(hrs)
50,000
Touch Screen Projected capacitive 10 point multitouch
View
Angel
Horizontal 170° 170° 178°
Vertical 130° 170° 178°
Other LED
Power Off - "No Light"
Power ON -"Blue"
Standby -"orange"
