SPC-800(M) User Manual 12
1.3.5 Button extension for built in BOR-DE115W & BOR-DE121W
Multi Touch Industrial Monitor (Customize model for
Customer)
Advantech Part Number BOR-DE115W-B100A BOR-DE121W-B100A
General
Weight
6.8g(W/O ARM Mount)
7.2g(W ARM Mount)
7.6Kg(W Vesa Mount)
9.6g(W/O ARM Mount)
10Kg(W ARM Mount)
10.4Kg(W Vesa Mount)
System
Dimension
(W x D x H mm)
402.19mm x 333.19mm x 67mm
(W/O ARM Mount)
402.19mm x 333.19mm x
160mm (W ARM Mount)
402.2mm x 333.2mm x 86.6mm
(W Vesa Mount)
546.69mm x 420.34mm x 67mm
(W/O ARM Mount)
546.69mm x 420.34mm x 160mm
(W ARM Mount)
546.69mm x420.34mm x 86.6mm
(W Vesa Mount)
Monitor Board
Dimension
(W x D x H mm)
145 x 104 x20 mm
Enclosure
Front bezel: Die cast aluminum alloy (RAL9011)
Back housing: Die cast aluminum alloy (RAL9011)
Mounting
ARM mounting (Pendant and Pedestal)
VESA mounting
Power Input
Voltage
24VDC +25%/- 20%
Power
Consumption
(DP+HDM+RX)
20.6W 32W
System Design Fanless
I/O
USB USB 2.0 x1 (Type B) + Host USB x2
Video output DP port x1, HDMI x1
CDI+ port
RX: RJ-45 port x1
Chip: Valens VS2010 , 100M
For Long distance function, please use CAT6 Ethernet Cable
Display
Backlight Control
Software(API) under Windows, need to connect PR4000 or PR3100
Box PC
Display Type TFT LCD TFT LCD
Display Size 15.6" 16:9 21.5" 16:9
Max. Resolution HD 1366 X 768 FHD 1920x1080
LCD Luminance
(cd/m²)
400 250
Backlight MTBF
(hrs)
50,000
Touch Screen Projected capacitive 10 point multitouch
View
Angel
Horizontal 170° 178°
Vertical 130° 178°
Other LED
Power Off - "No Light"
Power ON -"Green"
Standby -"orange"
To Next Page
