SPC-800(M) User Manual 8
1.3.3 Button extension & Without IO RJ-45 Port for built in SPC-815-
M7AP & SPC-821-M7AP Multi Touch Industrial Monitor
Advantech Part Number SPC-815-M7AP SPC-821-M7AP
General
Weight
6.8g(W/O ARM Mount)
7.2g(W ARM Mount)
7.6Kg(W Vesa Mount)
9.6g(W/O ARM Mount)
10Kg(W ARM Mount)
10.4Kg(W Vesa Mount)
System
Dimension
(W x D x H mm)
402.19mm x 333.19mm x 67mm
(W/O ARM Mount)
402.19mm x 333.19mm x
160mm (W ARM Mount)
402.2mm x 333.2mm x 86.6mm
(W Vesa Mount)
546.69mm x 420.34mm x 67mm
(W/O ARM Mount)
546.69mm x 420.34mm x 160mm
(W ARM Mount)
546.69mm x420.34mm x 86.6mm
(W Vesa Mount)
Monitor Board
Dimension
(W x D x H mm)
145 x 104 x20 mm
Enclosure
Front bezel: Die cast aluminum alloy
Back housing: Die cast aluminum alloy
Mounting
ARM mounting (Pendant and Pedestal)
VESA mounting
Power Input
Voltage
24VDC +25%/- 20%
Power
Consumption
(DP+HDM+RX)
20.6W 32W
System Design Fanless
I/O
USB USB 2.0x1 (Type B) ,USB 3.0 x2,USB 2.0 x 1 (Front)
Display Port DP Port x1
HDMI Port HDMI Port x1
Display
Backlight Control OSD setting brightness
Display Type TFT LCD TFT LCD
Display Size 15.6" 16:9 21.5" 16:9
Max. Resolution HD 1366 X 768
FHD 1920
X1080
(option)
FHD 1920x1080
LCD Luminance
(cd/m²)
400 450 250
Backlight MTBF
(hrs)
50,000
Touch Screen Projected capacitive 10 point multitouch
View
Angel
Horizontal 170° 170° 178°
Vertical 130° 170° 178°
Other LED
Power Off - "No Light"
Power ON -"Blue"
Standby -"orange"
Button
Emergency button RAFI 22 FS+ (2NC) 1.30.273.511/0300 Emergency Stop button *1
Push button
RAFI 22 FS+ Push button (1NC1NO) ,Green(1.30.270.021/
2500),Red (1.30.270.021/2300),Blue (1.30.270.021/2600)
Button Cable
SPEC
28#, support 24V 0.5A
