Advantech WISE-4000 Series User Manual

67 WISE-4000 User Manual
Chapter 4 System Configuration
Table 4.1: Application Scenario of WISE-4051 RS-485 Port with ADAM-
4000 Modbus I/O Module
WISE-4051 ADAM-4055 WISE-4051 ADAM-4017+
Bit Status
Mapped
Modbus
Address
I/O
Slave
Modbus
Address
Word Status
Mapped
Modbus
Address
I/O
Slave
Modbus
Address
Ch0 01001 DI0 00001 Ch0 41001 AI0 40001
Ch1 01002 DI1 00002 Ch1 41002 AI1 40002
Ch2 01003 DI2 00003 Ch2 41003 AI2 40003
Ch3 01004 DI3 00004 Ch3 41004 AI3 40004
Ch4 01005 DI4 00005 Ch4 41005 AI4 40005
Ch5 01006 DI5 00006 Ch5 41006 AI5 40006
Ch6 01007 DI6 00007 Ch6 41007 AI6 40007
Ch7 01008 DI7 00008 Ch7 41008 AI7 40008
Ch8 01009 DO0 00017 Ch8 41009
Ch9 01010 DO1 00018 Ch9 41010
Ch10 01011 DO2 00019 Ch10 41011
Ch11 01012 DO3 00020 Ch11 41012
Ch12 01013 DO4 00021 Ch12 41013
Ch13 01014 DO5 00022 Ch13 41014
Ch14 01015 DO6 00023 Ch14 41015
Ch15 01016 DO7 00024 Ch15 41016
Ch16 01017 Ch16 41017
Ch17 01018 Ch17 41018
Ch18 01019 Ch18 41019
Ch19 01020 Ch19 41020
Ch20 01021 Ch20 41021
Ch21 01022 Ch21 41022
Ch22 01023 Ch22 41023
Ch23 01024 Ch23 41024
Ch24 01025 Ch24 41025
Ch25 01026 Ch25 41026
Ch26 01027 Ch26 41027
Ch27 01028 Ch27 41028
Ch28 01029 Ch28 41029
Ch29 01030 Ch29 41030
Ch30 01031 Ch30 41031
Ch31 01032 Ch31 41032
