Using Progressive scan/component video 1 inputs
Installation(continued)
SET-TOP BOX
RR GGBB
RR GGBB
WW
RR
WW
RR
To Y output
To audio
outputS
To P output
B
To P output
R
WW
YY
RR
GG
BB
Yellow (video)
white (audio L/MONO)
red (audio R, P /C )
Green (Y)
Blue (P /C )
R
B
R
B
Rear terminals
To view digital TV program
Connect Set-Top Box(or DVD) to PROGRESSIVE SCAN/COMPONENT VIDEO (1) inputs
as the figure above.
Press AV to display video input menu.
Select Component 1 by using CH+ or CH-.
Press VOL+ or VOL- to confirm.
1
2
3
4
Signal
Please refer to the owner's manual of your specific equipment as well.
13
Y
L
/MONO
AUDIO
R
P C
B B
R
P C
R
PROGRESSIVE SCAN
/COMPONENT VIDEO
To Next Page
