5. The installation position should be such that interference from other electrical devices is avoided.
6. The inverter needs to be installed on a firm and sturdy surface, such as a wall, or metal brackets.
7. The installation surface should be perpendicular to the horizontal line. Please refer to Figure 9
Figure 8: Installation space
Ensure there is sufficient space (clearance) for heat releasing. Generally, the below listed clearance requirements
should be met:
Position Minimum clearance
Lateral
200mm
Top
450mm
Bottom
450mm
Table 8: Minimum clearance
Figure 9: Installation position
Do not remove any inverter part or component, otherwise damage to the device and physical injury
may occur.
