5.4.5 System Information
Press “
” and “ ” in the main interface to select “System Information”, and then press “ENT” to view the parameters
shown in figure 22.
System Information
Part No .
Serial No .
Soft Ver
Cert . Area
Run Param
Figure 22: System information
The system information include product model, serial number, software version and certificate version.
System Ver
Version1 : V1.05
Version2 : V1.05
MCU Version : V1.05
Figure 23: System version
5.4.6 Faults
Press “
” and “ ” in the main interface to review the fault history, and then press “ENT” to view the sub-menu shown
in figure 24.
Fault
1: A005 Grid under freq
2: A001 Input under Volt
3:
1
Figure 24: Fault information
There are maximal 8 fault information logs in the record shown in figure 24; if no faults are present, the system will
display the message “No Fault”. Refer to section 5.4.2 for detailed information.
5.4.7 Inverter control
Press “
” and “ ” in the control interface, and then press “ENT” to view the sub-menu shown in figure 25.
Control Menu
On/Off
Clear
Restart
Factory
Figure 25: Control interface
Refer to the below table for detailed information.
