Page #43 background image
Width of the back of the appliance 559 mm
Depth of the appliance 569 mm
Built in depth of the appliance 548 mm
Depth with open door 1022 mm
Ventilation opening minimum size. Opening placed
on the bottom rear side
560x20 mm
Mains supply cable length. Cable is placed in the
right corner of the back side
1500 mm
Mounting screws 4x25 mm
2.2 Electrical connection
WARNING!
Risk of fire and electric shock.
All electrical connections should be made by a qualified electrician.
The appliance must be earthed.
Make sure that the parameters on the rating plate are compatible with the electrical ratings
of the mains power supply.
Always use a correctly installed shockproof socket.
Do not use multi-plug adapters and extension cables.
Make sure not to cause damage to the mains plug and to the mains cable. Should the mains
cable need to be replaced, this must be carried out by our Authorised Service Centre.
Do not let mains cables touch or come near the appliance door or the niche below the
appliance, especially when it operates or the door is hot.
The shock protection of live and insulated parts must be fastened in such a way that it
cannot be removed without tools.
Connect the mains plug to the mains socket only at the end of the installation. Make sure
that there is access to the mains plug after the installation.
If the mains socket is loose, do not connect the mains plug.
Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.
Use only correct isolation devices: line protecting cut-outs, fuses (screw type fuses removed
from the holder), earth leakage trips and contactors.
The electrical installation must have an isolation device which lets you disconnect the
appliance from the mains at all poles. The isolation device must have a contact opening
width of minimum 3 mm.
Fully close the appliance door before you connect the mains plug to the mains socket.
This appliance is supplied with a main plug and a main cable.
43/152
SAFETY INSTRUCTIONS

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the AEG BPS335061M and is the answer not in the manual?

AEG BPS335061M Specifications

General IconGeneral
Oven sizeMedium
Oven typeElectric
Cleaning typePyrolytic
Bottom heatingYes
Number of ovens1
Total oven power3490 W
Oven net capacity- L
Full surface grill-
Oven cooking methodFan-forced
Oven thermostat range30 - 300 °C
Total oven(s) interior capacity72 L
Cord length1.5 m
Noise level44 dB
Control typeButtons, Rotary
Display typeLED
Product colorBlack, Steel
Control positionFront
Housing materialGlass, Stainless steel
Appliance placementBuilt-in
AC input voltage220 - 240 V
Energy efficiency scaleA+++ to D
Energy consumption (standby)0.99 kWh
Energy efficiency index (EEI)81.2
Energy consumption (conventional)0.93 kWh
Energy consumption (forced convection)0.69 kWh
Lamp typeHalogen
Weight and Dimensions IconWeight and Dimensions
Depth568 mm
Width594 mm
Installation compartment depth550 mm
Installation compartment width560 mm
Installation compartment height600 mm
