Step 1 Open the door fully and hold both
hinges.
Step 2 Lift and pull the latches until they
click.
Step 3 Close the oven door halfway to the
first opening position. Then lift and
pull to remove the door from its seat.
Step 4 Put the door on a soft cloth on a sta‐
ble surface.
Step 5 Hold the door trim (B) on the top edge
of the door at the two sides and push
inwards to release the clip seal.
Step 6 Pull the door trim to the front to re‐
move it.
Step 7 Hold the door glass panels by their
top edge and carefully pull them out
one by one. Start from the top panel.
Make sure the glass slides out of the
supports completely.
67/152
CARE AND CLEANING
