Machine Parts (Fig. 1)
A Top view (see Fig. 2)
B Bean container with lid
C Service cover
D Selection dial for steam and hot water
E Height-adjustable dispenser with
outlets
F Swivel nozzle for steam and hotwater
with removable frothing aid
G Coffee grounds container (removable)
H Drip grille
I Drip tray float
J Drip tray
K Type plate (at top behind service cover)
L Control panel (see Fig. 3)
M Water tank with fill level indicator
(removable)
N Test strip for water hardness
O Measuring spoon with cleaning brush
Top View (Fig. 2)
P Cup rack
Q Opening for ground coffee
with lid (ground coffee filler)
R Bean-container position setting
S Service cover release button
T Release catch for removing grinding
ring
U Lever for setting grinding texture
Control Panel (Fig. 3)
a Key for 2 cups of coffee (with
indicator)
b Key for 1 cup of coffee (with indicator)
c "Coffee Quantity" key (with indicator)
d "Cup Measure" key (with indicator)
e "Descale" key (with indicator)
f "Clean" key (with indicator)
g "Steam Pre-selector" key (with
indicator)
h "On/Off" key (with indicator)
i "Coffee machine heating" indicator
j "Empty grounds container" indicator
k "Fill water tank" indicator
