- 11 / 50 - BN 09 2671/01/01
4 CONNECTIONS (REFER TO THE PRODUCT
DRAWING)
ANY OPERATION ON THE EQUIPMENT SHALL BE CARRIED OUT BY QUALIFIED
PERSONNEL AWARE OF SPECIFIC ELECTRICAL HAZARDS AND PRECAUTIONS TO
BE TAKEN. NEVER ASSUME THE ABSENCE OF VOLTAGE, ALWAYS CHECK WITH
A VOLTMETER BEFORE ANY OPERATION ON A SYSTEM.
Always make the connections with power off and the circuit-opening devices in the "open" position:
- Mains and load protective devices or disconnecting switch open.
- Battery protective device or disconnecting switch open.
- Power switch to "OFF" (option).
If an external protection or cut-off device is mounted between the charger output and
the battery shunt, it is necessary to provide an auxiliary contact "position open" of
this device to open the battery current measurement to avoid damaging the control
system.
The external battery shunt must be inserted on the negative polatity of the battery,
never on the positive polarity as this will damage the charger control board.
Please contact AEG Power Solutions Customer Service Department.
4.1 MAINS INPUT CONNECTION
DANGER, IF THE RECTIFIER IS EQUIPPED WITH AN OPTIONAL INPUT FILTER:
MAINS INPUT: HIGH LEAKAGE CURRENT.
EARTH CONNECTION IS MANDATORY BEFORE CONNECTING THE MAINS SUPPLY.
It is mandatory to install a mains input protection in the mains switchboard, upstream the charger.
Recommended rating: 2 x charger nominal input current.
- The nominal input current is specified on the electrical characteristics page of the customer drawing package.
- As standard, the inrush current is less than 20 times the input current.
Connect the mains input to the terminal block located in the connection area.
The Protect RCD TPRe TD units are not phase rotation sensitive.
Remember to connect the earth bar to the site reference earth.
