AEG PROTECT RCS User Manual

- 5 / 50 - BN 09 2671/01/01
2 PRESENTATION OF THE SYSTEM
The battery charger is composed of the following items :
1. Floor standing cabinet with air inlets and outlets, including a natural cooling and a fan forced cooling roof
depending on the system rating
2. Charger electrical components on a mounting plate
3. Mains transformer
4. Options depending on the system configuration
The door of the cabinet is equipped with the man-machine interface (MMI) allowing the operation and monitoring
of the system.
Cabinet with natural cooling roof Components internal mounting plate (door open)
The PROTECT RCS TPRe TD range offers the following standard ratings and cabinet cooling features :
PROTECT RCS TPRe TD
BATTERY
V
OLTAGE (VDC)
24 36 48 60 110 125/127
Output current (A)
Cabinet cooling :
N=natural
F = forced
Cabinet weight (kg)
20A
(N)
110kg
20A
(N)
110kg
20A
(N)
120kg
20A
(N)
120kg
20A (N)
220kg
20A (N)
220kg
25A
(N)
110kg
25A
(N)
110kg
25A
(N)
120kg
25A
(N)
120kg
25A (N)
220kg
25A (N)
220kg
40A
(N)
120kg
40A
(N)
120kg
40A
(N)
140kg
40A
(N)
140kg
40A (N)
240kg
40A (N)
240kg
60A
(N)
140kg
60A
(N)
140kg
60A
(N)
160kg
60A
(N)
160kg
60A (N)
260kg
60A (N)
260kg
100A
(N)
160kg
100A
(N)
160kg
100A
(N)
180kg
100A
(N)
180kg
100A
(F)
280kg
100A (F)
280kg
“N means cabinet natural cooling, “F” means cabinet fan forced cooling
Air inlets
MMI
Front door options
Charger mounting
plate and options
Front door
options
Transformer behind
the mounting plate
