1 INTRODUCTION
This manual is designed to familiarize the user with the operating principles, use and maintenance of the PROTECT
RCS TPRe TD range of rectifiers fitted in floor mounted cabinets. TPR means Three Phase Rectifier and "e" means
"evolution" brought by the GCAU control card. TD means that this range is designed to fulfill the electrical energy
Transmission and Distribution (T&D) market specifications, although it can be used in other applications provided
that the related specifications and rules are compatible.
To use the system properly, the user should first read this manual carefully.
AEG is not be responsible for damage due to improper use, neglect, alterations, or use of other than original parts
without our written consent.
Equipment access areas:
- Operator: door closed.
- Maintenance personnel: door open.
IMPORTANT RECOMMENDATIONS:
ANY OPERATION ON THE EQUIPMENT SHOULD BE CARRIED OUT BY QUALIFIED PERSONNEL,
AWARE OF SPECIFIC ELECTRICAL HAZARDS AND PRECAUTIONS TO BE TAKEN.
LETHAL VOLTAGES EXIST PERMANENTLY ACROSS THE BATTERY TERMINALS.
DO NOT MAKE ASSUMPTIONS AS TO THE PRESENCE OR ABSENCE OF A VOLTAGE: CHECK
USING A VOLTMETER OR AN ELECTRICAL SAFETY TESTER.
WEEE INFORMATION
The disposal of this product is covered by a selective processing of some components. For
this provision of services, please contact our Customer Service.
Refer to standards 2002/95/EC (LSDEEE or RoHS) and 2002/96/EC (WEEE)
For general information about operating principles of the charger: please refer first to Chapter 7 "Functional
description".
SYSTEM DRAWINGS:
This manual comes with a standard drawing package.
These documents will be needed for any operation at site.
All the documents are accessible on AEG Power Solution download center web site, the link to this
site is available on the system.
