Ground Resistance Tester Models 3711 and 3731
- 17 -
Current
Press A to enter the current function. True RMS current measurements
are possible up to 30.00A (Fig. 12).
Above 30Arms, OL will be displayed and the test must be discontinued.
The beeper is also activated during OL.
Range Resolution
1 to 299mA 1mA
0.300 to 2.999A 0.001A (1mA)
3.00A to 29.99A 0.01A (10mA)
A
Ω
ON
OFF
Figure 12
